Reachability pre-flight

Every time a scene loads, RoboSandbox runs a fast kinematic check: can the configured arm actually reach each object? Warnings print before any physics runs, so bad placements surface instantly instead of after four replans.

reachability warning

What it checks

For each object in the scene, the checker asks three questions, matching the v0.1 Pick skill's own waypoints:

Phase Target Why it matters
approach object center + 11.3 cm above, palm-down Must be reachable to start a pick
grasp object center + 1.3 cm above, palm-down The actual grip pose
lift object center + 19.3 cm above, palm-down Must be reachable to pass the 50 mm success criterion

Each target is fed to the same DLSMotionPlanner that Pick uses at runtime (multi-seed retries, joint-limit clipping, z-down orientation). If IK doesn't converge from the home pose within 400 iterations, the object is flagged with the first failing phase.

What a warning looks like

reachability: 1 unreachable object(s):
  - red_cube: approach target (1.200, 0.000, 0.173) — IK (none) did not converge
    in 400 iters (pos_err=0.6064m > tol=0.001m)

Three things the warning tells you:

  1. Which object — red_cube
  2. Which phase failed first — approach (before grasp, before lift)
  3. How far off IK was — pos_err=0.6064m: 60 cm short. Huge number means structurally out of reach; a few centimeters means the grasp is at the edge of the workspace and may succeed with different IK seeds at runtime.

When it fires

Four entry points print reachability warnings automatically:

  • robo-sandbox run "pick up the red cube" — prints before the agent loop starts.
  • robo-sandbox-bench — prints one warning block per task (once, at task load, not per seed).
  • examples/run_custom_task.py — between the task summary and the seed loop.
  • Programmatic use — call from robosandbox.scene.reachability import check_scene_reachability and do what you like with the returned list[UnreachableObject].

Warnings do not abort. The agent runs anyway — surprises are a legitimate test case, and kinematics is not the only reason a pick fails. Fail-fast is the agent's replan loop's job.

Programmatic use

from pathlib import Path
from robosandbox.scene.reachability import check_scene_reachability, format_warnings
from robosandbox.tasks.loader import load_task

task = load_task(Path("path/to/my_task.yaml"))
warnings = check_scene_reachability(task.scene)

if warnings:
    print(format_warnings(warnings))
    # decide: skip? adjust positions? run anyway?

Each warning is an UnreachableObject:

@dataclass(frozen=True)
class UnreachableObject:
    id: str                                  # scene-object id
    first_failed_phase: str                  # 'approach' | 'grasp' | 'lift'
    target_xyz: tuple[float, float, float]   # world-frame IK target that failed
    detail: str                              # full error from the IK solver

What it doesn't catch

Kinematics isn't physics. The pre-flight check:

  • Checks reach from the home pose only. If the arm has already moved (e.g. for a second pick in a multi-step task), feasibility from that pose can differ.
  • Ignores collisions. A reachable pose may still fail because a fingertip sweeps through a neighboring cube on the way down.
  • Ignores gripper width. A graspable object may still slip if the grasp planner picks a width too wide for friction.
  • Ignores dynamics. Heavy objects, low friction, accidental contacts — all show up only at runtime.

For those, the Agent replan loop is your safety net. See the replan loop guide.

Tuning

The defaults match the Pick skill's geometry. If you're using a custom skill with different approach/lift distances, pass them explicitly:

check_scene_reachability(
    scene,
    grasp_height_offset=0.02,   # bigger offset — for taller grippers
    approach_offset=0.15,       # farther approach
    lift_height=0.10,           # shorter lift — enough to clear neighbors
)

Skipped object kinds

drawer objects are skipped — they use OpenDrawer / CloseDrawer, not Pick. Reachability of a drawer body isn't the same as pickability. Add more exemptions in reachability.py:check_scene_reachability if you introduce object kinds that don't participate in top-down grasps.
