VLM tool-calling

What this is — and what it isn't

The browser viewer uses a regex-based planner (StubPlanner) by default. No API key, no VLM, no network call. It handles everyday phrasings like "pick up the red cube" without any model.

A VLM (Vision-Language Model) becomes relevant when you want richer natural-language understanding — sentences the regex grammar doesn't cover, multi-step descriptions, or reasoning from the camera image. You enable it via the CLI:

export OPENAI_API_KEY=sk-...
uv run robo-sandbox run "stack the red cube on the green cube" --vlm-provider openai

The VLM sees the task string + a live camera frame, then emits tool calls that drive the same skills the viewer uses. The agent loop is identical — only the planner changes.

This page shows the exact path from a skill definition in Python to a SkillCall coming back from a VLM.

walkthrough

The walkthrough script examples/vlm_tool_calling_walkthrough.py prints every step with a mock VLM client, so you can run it without an API key.

The pattern

┌──────────┐       schemas           ┌─────────────────┐
│  Skills  │ ─────────────────────► │ Tool definitions│
└──────────┘                          └────────┬────────┘
                                                │ sent with task + image
                                                ▼
                                         ┌──────────────┐
                                         │  VLM (OpenAI │
                                         │  Ollama, ...)│
                                         └──────┬───────┘
                                                │ tool_calls
                                                ▼
                                         ┌──────────────┐
                                         │  SkillCall[] │ → Agent loop executes
                                         └──────────────┘

VLMPlanner is short enough to read in one sitting: agent/planner.py. What follows is the whole flow.

1. Skills become tool definitions

Every skill exposes name, description, parameters_schema (JSON schema). VLMPlanner._tool_schemas() wraps them in OpenAI's function format:

{
  "type": "function",
  "function": {
    "name": "pick",
    "description": "Pick up an object from the table. Use when the agent needs to grasp and lift a specific object by name.",
    "parameters": {
      "type": "object",
      "properties": {
        "object": {
          "type": "string",
          "description": "Natural-language name of the object to pick, e.g. 'blue cube'."
        }
      },
      "required": ["object"]
    }
  }
}

A synthetic done tool is added so the model can say "nothing to do" without falling back to prose.

The skill author only writes parameters_schema as ordinary JSON schema. The planner wraps it in the provider-specific tool format.

2. Task + observation become a VLM request

VLMPlanner._build_messages() assembles a 2-message chat:

[
  {"role": "system", "content": "You are a robotic manipulation agent..."},
  {"role": "user", "content": [
    {"type": "text", "text": "Task: pick up the red cube and put it on the green cube"},
    {"type": "text", "text": "Known objects in the scene (use their natural names):\n{\"red_cube\": {\"xyz\": [0.4, 0.0, 0.06]}, ...}"},
  ]}
]

The user message carries three useful pieces of context:

  • The task string verbatim.
  • A scene summary from obs.scene_objects — gives the model exact object ids to use instead of guessing pronouns.
  • The current RGB frame as a data URL — VLMs see what the arm sees.

On a replan, one more text block is appended:

{"type": "text", "text": "Previously-failed steps — do NOT repeat them unchanged:\n[{\"step_idx\": 1, \"skill\": \"pick\", \"args\": {...}, \"reason\": \"object_not_found\"}]"}

That is the ReAct feedback loop in practice: failed steps become context for the next plan.

3. Model response becomes SkillCalls

The VLM returns OpenAI-shaped tool calls:

{
  "content": null,
  "tool_calls": [
    {"id": "call_abc123", "name": "pick",
     "arguments": "{\"object\": \"red_cube\"}"},
    {"id": "call_def456", "name": "place_on",
     "arguments": "{\"target\": \"green_cube\"}"}
  ],
  "finish_reason": "tool_calls"
}

_parse_tool_calls() turns each response into a SkillCall(name, arguments, tool_call_id). Two details matter:

  1. arguments is parsed as JSON. If it's malformed, the SkillCall falls back to {} rather than crashing the agent.
  2. If the model emits the synthetic done tool first, parsing stops and the planner returns an empty plan — the agent treats that as "already done."

4. Recovery when the model emits prose

Smaller or local models sometimes ignore the tool interface and answer in prose. VLMPlanner.plan() detects that and retries once with a nudge:

{"role": "user", "content": "Please respond with tool calls only — no prose."}

If the second try also returns prose, the planner gives up and returns an empty plan.

n_vlm_calls tells you whether that extra retry happened, which is useful when you are comparing models.

Running against real providers

Provider Setup Command
OpenAI export OPENAI_API_KEY=sk-... uv run robo-sandbox run "pick up the red cube" --vlm-provider openai
Ollama ollama serve & + ollama pull llama3.2-vision uv run robo-sandbox run "pick up the red cube" --vlm-provider ollama
Any OpenAI-compatible vLLM, together, groq, etc. uv run robo-sandbox run "..." --vlm-provider custom --base-url https://...
No VLM (regex) nothing uv run robo-sandbox run "pick up the red cube" — defaults to stub

All four paths use the same Planner interface. Swapping providers is just a flag change.

Zero-setup walkthrough

Run the walkthrough yourself — no API keys, no network:

uv run python examples/vlm_tool_calling_walkthrough.py

The output shows the tool definitions, the request payload, the canned tool-call response, and the parsed SkillCalls.

This is the easiest way to understand the pattern before plugging in a real model.

Cost & latency notes

  • Per episode: ~1–2 VLM calls for successful plans, +1 per replan. gpt-4o-mini ≈ $0.002/episode, gpt-4o ≈ $0.02.
  • Latency: ~1.5 s for gpt-4o-mini first token, ~0.5 s on Ollama with a warm model. This lives inside the agent loop — between PLAN and EXECUTE log lines.
  • Rate limits: OpenAIVLMClient fails fast on RateLimitError rather than silently retrying — surfaces the issue instead of hiding it in long waits.
